BigShot EFX Features

1
2
3
4
5
6
7
8

Output

¼” jack connects to your amplifier.

1

Footswitch 2

Turns Loop-2 on and off.

2

Loop-2 LED

Indicates Loop-2 is active.

3

Loop-2 Mute

Converts Loop-2 into a mute function to allow silent tuning.

4

Loop-2 Lift

Reduces ground loop hum by disconnecting the ground at the Return-2 jack.

5

Loop-1 Lift

Reduces ground loop hum by disconnecting the ground at the return-1 jack.

6

Loop-1 LED

Indicates Loop-1 is active.

7

Footswitch 1

Turns Loop-1 on and off.

8
1
2
3
4
5

Send

¼” output jack for the first effects loop.

1

Return

¼” input jack for the first effects loop.

2

Send

¼” output jack for the second effects loop.

3

Return

¼” input jack for the second effects loop.

4

PSU

Connection for 9-12 volt DC (center pin negative)

5
1
2
3
4
5

Connectors

Glass filled nylon housing is tougher than steel and provides isolation for reduced noise. Nickel silver contacts will not tarnish.

1

14-Gauge Steel

Prevents circuit board from being torqued which could lead to part failure.

2

Extra Durable Switches

Switches with metal outer casing are rated at over 20,000 cycles for added durability.

3

Mil-Spec PCB

Full ground plane for noise free performance. Double sided through hole solder points for durability.

4

Footswitch

Heavy duty 9 pole footswitches control signal flow and LED indicators.

5

BigShot EFX Resources

Part no: R800 7214 00
