Specifications | ||
---|---|---|
Audio circuit type: | Active with FET dim circuits | |
Number of channels: | Mono or Stereo operation | |
Frequency response: | 20Hz - 20kHz ±0.5dB | |
Dynamic range: | 106dB | |
Gain: | +45dB (EXT mic input) | |
Total harmonic distortion: | <0.007% | |
Intermodulation Distortion: | <0.005% | |
Input Impedance: | 20 kΩ (Program), 2 kΩ (EXT mic) | |
Output Impedance: | 225 Ω (1/4" output) | |
Noise Floor: | -86dBu | |
Maximum Input: | +14dBu (Program) | |
Features | ||
Extras: | Dim Attenuation: -6dB to -80dB | |
General | ||
Conditions: | For use in dry locations only between 5°C and 40°C | |
Warranty: | Radial 3-year, transferable |
Frequency Response
![](https://www.radialeng.com/wp-content/uploads/2018/04/studioq-graph-frequency-response-768x345.jpg)
What do these graphs mean? Learn what to look for and why it matters.
